PROS18650 1.3Ah（15C）

PROS18650 1.3Ah（15C）
Model：PROS18650 1.3Ah（15C）
Size：H:65.1±0.2mm;D:≤18.5mm.
General performance：
Battery Impedance:                    13±2mΩ
Nominal Voltage：                     3.6V
Minimum Capacity：                   1300mAh( 0.5C to 2.75V cut-off )
Battery Weight:                        41±1g
Charge Ending Voltage：                4.20±0.05V
Charge Ending Current：                0.02C
Standard Charging Current：             0.5C
Fast Charge Circuit：                   1.0C
Standard Discharging Current：           0.5C
Max. Continue Discharging Current：      15C
Max. Moment Discharging Current：       20C(<20S)
Ending Voltage of discharging:             2.75V (Discharging Current >5C, Ending Voltage 2.5V ) Cycle life
Cycle life：
Testing Method:25±2℃ condition，0.5C CC/CV to 4.10+/-0.05V，0.02C cut-off；rest 5min；15C CC to 2.75V；rest 15min；recycle until the successive two times capacity are the first capacity’s 70%,the life is ending.
Standard：300times cycles discharging capacity≥70% first capacity.
Storage Temperature
Six months:  -20-45℃，Twelve months: -20-25℃
Working Temperature of charging and discharging：
Discharge：At -20-60℃，Load resistance 13±2mΩ，Cut-off 2.75V。(Charging Current >5C, Ending Voltage 2.5V ).
Charge： At0℃-10℃（0.2C),10℃-45℃（0.5C)，Load resistance 13±2mΩ，Cut-off 4.20±0.05V.
Humidity: <85%RH.
